Hand & Basic Wire Armatures

Full Size Human Hand
The Full Size Human Hand Armature is based around a central 8mm thick aluminium palm block with an M4 rigging point. The wrist assembly is a 9mm brass link plate assembly with an 8mm diameter aluminium forearm. The fingers are assembled using 6mm standard brass link plate assemblies with nickel plated steel connectors/stud ends. The stud ends are secured into the aluminium palm block using Loctite 270 high strength thread lock.

Malvern Armatures - Quality in Motion - Stop Motion Animation Armatures
Shown as a Pair

Key Features

8mm Diameter Aluminium Forearm
9mm Diameter Brass Wrist Link Plate Assembly
8mm Thick Aluminium Palm Block
M4 Rigging Point

6mm Diameter Brass Standard Link Plate Assemblies

Nickel Plated Steel Fingers with Integrated Balls
Stainless Steel Link Plate Screws
Fully Assembled using Loctite 270
1 x 75mm Rigging Stud
2mm & 2.5mm Allen Keys

Hand Armature (Each)
Drawing Number MA-085
Parts List Item PL-163
£155.00



Basic Wire Hands
Each 5 finger aluminium wire hand comprising a 8.7mm diameter cupped stainless steel washer with 5x1mm twisted aluminium wire fingers and a 3 strand 1mm twisted aluminium wire wrist. The fingers can be cut to length as required during final assembly. Each hand is supplied with 2x15mm lengths of K&S Square Brass Tube #8152 and 1x22mm length of K&S Tube Brass Square #8153. All components require final assembly using 2 Part Epoxy Glue as per the instructions below. For a PDF copy of the assembly instruction click HERE.

Do It Yourself Malvern Armatures - Quality in Motion - Stop Motion Animation Armatures
2 x 5 Finger Aluminium Wire Hands with
Square K&S Brass Tube
Fitted
Malvern Armatures - Quality in Motion - Stop Motion Animation Armatures
2 x 5 Finger Aluminium Wire Hands with
Square K&S Brass Tube
Key Features

8.7mm Cupped Palm Washer
5x1mm Aluminium Wire twisted fingers
3 strand 1mm Aluminium Wire twisted Wrist
4 x #8152 K&S Square Tube
2 x #8153 K&S Square Tube

This product requires final assembly

8.7mm Cupped Palm Washer
5x1mm Aluminium Wire twisted fingers
3 strand 1mm Aluminium Wire twisted Wrist
4 x #8152 K&S Square Tube
2 x #8153 K&S Square Tube

Fully Assembled

Basic Wire Hands (Pair)
Drawing Number MA-066
Parts List Item PL-046
£10.00

Basic Wire Hands (Pair) - Fitted
Drawing Number MA-066
Parts List Item PL-70
£25.00


Malvern Armatures - Quality in Motion - Stop Motion Animation Armatures
For a PDF Copy CLICK HERE
